- High power density PCB design.
- Transformer efficiency 95-98%.
- Support design customization.
- Design of DC-DC Application Circuit Flyback circuit.
- Operating temperature: –40 °C to +125 °C
- turns Ratio: 1:1:1
- Rated Current: 820mA
- Insulation Test Voltage: 3KVAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 17:25:25
- Rated Current: 320mA
- Insulation Test Voltage: 2500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 12:5:5
- Rated Current: 780mA/640mA
- Insulation Test Voltage: 500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 1:2:2
- Rated Current: 640mA/390mA
- Insulation Test Voltage: 500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 2:3
- Rated Current: 320mA
- Insulation Test Voltage: 3KVAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 1:2:2
- Rated Current: 1A/500mA
- Insulation Test Voltage: 500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 1:2:2
- Rated Current: 640mA/260mA
- Insulation Test Voltage: 500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 4:9:9
- Rated Current: 320mA
- Insulation Test Voltage: 2500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 3:8:8
- Rated Current: 320mA
- Insulation Test Voltage: 3.0KVAC/500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 11:15:15
- Rated Current: 500mA
- Insulation Test Voltage: 2000VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 12:5:5
- Rated Current: 1A
- Insulation Test Voltage: 500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 2:1:1
- Rated Current: 1A
- Insulation Test Voltage: 500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 15:22:22
- Rated Current: 320mA
- Insulation Test Voltage: 2500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 15:17:17
- Rated Current: 320mA
- Insulation Test Voltage: 2500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 4:9:9
- Rated Current: 640mA/320mA
- Insulation Test Voltage: 1500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 5:9:9
- Rated Current: 410mA/320mA
- Insulation Test Voltage: 1500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 1:2:2
- Rated Current: 640mA/320mA
- Insulation Test Voltage: 1250VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- turns Ratio: 13:11:11
- Rated Current:320mA
- Insulation Test Voltage: 2500VAC
- Application: Drive isolation circuit
- Operating temperature: –40 ℃ to +125 ℃
- Small size
- Inductance range: 0.45mH
- turns Ratio: 1:1
- Rated Current: 0.5A
- Insulation Test Voltage: 1.5KVDC
- Operating temperature: –40 ℃ to +125 ℃
- Flyback transformers
- Coupled inductors in SEPIC applications
- Common mode filter chokes.
