Fangcheng Electronics (Dongguan) Co., LTD., committed to the development and production of module power patch current transformer, 100% domestic R & D and production, synchronous to provide customers with domestic commitment, products meet: Industrial grade/general military grade/seven specialized/military grade (refer to GJB33A/GJB128A) standards, breaking through the restrictions of imported foreign magnetic components of the same specifications, to provide comprehensive technical support to domestic customers, products used in: module communication power supply, rail transit power supply, and industrial control power supply.

Transformer patch 8 Series of specifications and application:FC-SCT4.2/4.6/5.0/6.0/8.3/8.5/2010-Series

1、FC-SCT series current sense transformers

2、There are two modes of regulating the output voltage of switched mode power sup-ply.

3、 For voltage regulation,the output voltage is measured directly and compared with a “reference voltage”.For current regulation (Current Mode,CM),the primary current is measured.The output voltage serves as a reference here.

4、Customer power application, module communication power supply

5、Module communication power supply, BMS, micro power supply

6、The product design structure is small volume, SMT automatic installation, meet the UL safety creepage distance:AC3750V

7、Design application circuit connection:
